System Application Guide SAG581126000
Spec. No. 581126000 (Model 700 NVBA ) Issue AD, November 23, 2009
Page 115 of 123
This document is property of Emerson Network Power, Energy Systems, North America, Inc. and contains confidential and proprietary information owned by Emerson Network Power, Energy
Systems, North America, Inc. Any copying, use, or disclosure of it without the written permission of Emerson Network Power, Energy Systems, North America, Inc. is strictly prohibited.
Electrical Connection Locations and Dimensions
Input Battery
Connections to Lists 21 through 24 Distribution Cabinets
Note: Battery busbars within distribution cabinets are rated for 2000A max.
For 2000A-4000A in List 2, make additional battery connections to inter-bay busbars.
2.000
2.000
1.000
0.625
0.625
0.750
0.625
0.625
0.750
0.625
Central
Office
Ground
0.750
FRONT VIEW
TOP OF
DISTRIBUTION
CABINET
BATTERY
(RETURN SIDE)
BUSBAR
BATTERY
(LOAD SIDE)
BUSBAR
3/8-16 CAPTIVE NUT, 14 PLACES (CUSTOMER MUST
SUPPLY LUG, BOLTS, AND ADDITIONAL HARDWARE.
BOLT LENGTH: 1-1/4")
1/4-20 CAPTIVE NUT, 20 PLACES (CUSTOMER
MUST SUPPLY LUG, BOLTS, AND ADDITIONAL
HARDWARE. BOLT LENGTH: 1-1/4")
0.750
0.625
0.750
0.625
GND RTN
(One Row
Cabinet Shown,
Others Similar)
+24V SUPPLY
