SMA Sunny Data Control V.5.0 - Manual (Page 40)

Initial Settings SMA Technologie AG
42 SDC-TEN081450 Technical Description
10. Choose the appropriate procedure according to the type of Bluetooth installation carried out.
11. Detect devices as described in chapter 8. 4 "Detecting Devices" (Page 49).
Installation was possible without a CD. Installation was only possible with a CD.
• Choose "Bluetooth Network IDs" or
"Individual Bluetooth devices" (point-to-
point connection) from the "Type of
display" drop-down menu.
• Click on
The Bluetooth IDs of detected devices are
searched for and listed.
• Choose the Bluetooth ID set at the inverter
and click on .
• Close the window with .
• Choose "Bluetooth COM ports" from the
"Display type" drop-down menu.
• Choose the virtual COM-Port which was
set up and click on .
• Close the window with .
