Sunny Data Control User Interface SMA Technologie AG
Technical Description SDC-TEN081450 33
7 Sunny Data Control User Interface
The Sunny Data Control user interface comprises three areas:
• (A) Menu Area
In the menu area you can access and use various Sunny Data Control functions by using the
menu bar. Using the symbols you can open the corresponding menu directly.
• (B) Plant diagram
The plant selected is displayed, along with its devices, which you have detected with Sunny
Data Control.
• (C) Display Area
In the display area you can display different views by selecting the appropriate tab.
- Overview
- Spot values (device overview)
- Parameter
- Channel recording (is shown once the devices have been detected).
B C
A
