Transferring Data to the Internet SMA Technologie AG
130 SDC-TEN081450 Technical Description
Channels (String)
This parameter specifies which channels are to be displayed in this component. The channel names
are listed, and separated by commas. Each name must be identical to that specified by the general
parameter "ChannelX" (see section 6.5.2).
ChanTextColor (Color)
This parameter defines the text color with which the individual channel texts are shown in the
component. The default value is "#ffffff" (white).
Title (String)
This parameter defines the text which is to be displayed as a title above the chart. If this parameter
is not declared, no title is displayed.
TitleColor (Color)
The color of the title is defined with this optional parameter. The default setting is "#ffffff" (white).
ValueColor (Color)
This parameter defines the text color with which the channel's values are displayed. The default
setting is "#ffff00" (yellow).
Example
Example
