Transferring Data to the Internet SMA Technologie AG
126 SDC-TEN081450 Technical Description
ChartColorX (Color)
This parameter defines the color of channel X. For "X", a channel number is entered, which
corresponds to the channels' sequential order as defined by the "Channels" parameter. The possible
numbers for "X" are 1 to 4. If this parameter is not declared, the following allocations occur:
1st channel => red
2nd channel => black
3rd channel => blue
4th channel => green
ChartStyle (String)
This parameter defines the component's style. It is possible to specify whether the area beneath the
line is to be filled in ("Fill"), or whether just the line itself ("Line") is to be displayed in the chart. This
parameter is case-sensitive. This parameter is optional. If this parameter is not declared, just the line
is displayed in the charts.
LegendBGColor (Color)
This parameter is used to set the background color of the entire legend. If this parameter is not
declared, the legend is displayed as transparent.
LegendTextColor (Color)
This parameter defines the text color used to display the channel text and units in the legend. This
parameter is optional. The default setting is #ffffff (white).
Example
This example sets the colors of the individual channels as follows:
1th channel => green
2rd channel => blue
3nd channel => black
4st channel => red
Example
