Transferring Data to the Internet SMA Technologie AG
128 SDC-TEN081450 Technical Description
ValLineColor (Color)
This setting defines the color of the axis partitioning in the chart. The partitioning is drawn
horizontally over the chart for each of the chart's scales (Y axis). By default, this optional parameter
is set to the color #595959 (gray).
12.8. 4 Device Field Display
The component "ViewerGrid" implements Sunny Data Control's online display in the Java applet.
With this component, individual devices are displayed in color in a chessboard-like field. In each of
these fields, the device's measuring channels are also displayed.
The corresponding component type is "de.sma.SunnyViewer.ViewerGrid“.
The arrangement of the individual device fields, the channel text settings, and the color settings, are
linked to Sunny Data Control's online display.
The applet also provides an enlargement function, which increases (left mouse button) or decreases
(right mouse button) the size of a device field. With this function, it is possible to achieve a better
view of the channel texts in each device field as, depending on the available space, it might not be
possible to display them in full.
Example
This example sets the color of the axis partitioning in chart "chart1" to black.
Example
