33
GV STRATUS Playout
Operator Manual
6 Under Manual Logo Transition, configure how the manually controlled logo events
(Logo 1 and Logo 2 buttons) are handled:
7 Continue configuring other settings on the other tabs or click Update Channel Type.
Configuring the SCTE-104 settings for the channel type
The SCTE-104 standard allows you to receive trigger messages from the audio or video feed
that flag the start and end points for commercial breaks. It allows you to receive trigger
messages in the SDI (Serial Digital Interface) signal that you can use to control the playlist.
To configure the SCTE-104 settings:
1 If you are continuing to configure a selected channel type, skip to step 2. To open the
Channel Settings page:
• In the top menu, click Settings.
• Click the Channel Types tab.
• In the Select Channel Type list, click the name of the channel type you want to
change.
2 Click the SCTE-104 tab.
3 Select the Act upon SCTE-104 splice request triggers check box to execute and log
received SCTE-104 splice messages. Clear the check box to ignore and not log the splice
messages.
4 Select the Block all SCTE-104 messages from being passed-through check box to
prevent all SCTE-104 messages from being sent through the PGM output on the SSP-
3801 card to other downstream equipment. Clear the checkbox to allow SCTE-104
messages to be sent through the PGM output.
5 Continue configuring other settings on the other tabs or click Update Channel Type.
Specifying the router sources
The Router Configuration tab contains the list of router sources that can be used to
configure the source events. The list of router sources and their mnemonics are obtained
from the devices configured with router systems when their SSP-3801 cards are registered
as a devices with GV STRATUS Playout and the Sync Source Mnemonics button is clicked.
For more information, see
Configuring the router for source events , on page 46.
Once you obtain the list of router sources that are available from the device, you can specify
up to 16 router sources which can be chosen when you configure a source event in a
schedule. The router sources are specified by assigning a router source to a box on the
Router Configuration tab.
Field Description
Fade In Type the time period over which the logo appears on screen when the
event is activated.
Fade Out Type the time period over which logo disappears from screen when the
event is deactivated.
Opacity Select the percentage of opacity between 0% (fully transparent) to 100%
(fully opaque).
