TYPICAL APPLICATIONS
Voltage Tripler with Regulator
The following figure shows the circuit required to triple
the input voltage, regulate the result and add a tempera-
ture gradient of –0.4%/
°
C. Note that the high input im-
pedance of RV requires appropriate noise countermea-
sures.
C4
R1
R2
+
10
µ
F
V REG = –8 V
= V RV V I = –5 V
R RV
100 k Ω
to
1 M
Ω
R
OSC
1 M
Ω
C1 +
10 µ F
C2 5 V +
10
µ
F
C3 +
10
µ
F
V
O
= –15 V
V
DD
= 0 V
14
13
12
11
10
9
8
1
2
3
4
5
6
7
R
RV
R 1
Converting a Voltage Tripler to a Voltage
Doubler
To convert this curcuit to a voltage doubler, remove ca-
pacitor C2 and short circuit CAP2– to V
O .
V
I
= –5 V
R
OSC
1 M
Ω
C1 +
10
µ
F
C2 5 V +
10
µ
F
C3 +
10
µ
F
V
O
= –15 V
V
DD
= 0 V
14
13
12
11
10
9
8
1
2
3
4
5
6
7
Parallel Connection
Connecting two or more chips in parallel reduces the
output impedance by 1/n, where n is the number of de-
vices used.
Only the single output smoothing capacitor, C3, is re-
V DD = 0 V
V I = –5 V
V
O
= –15 V
V REG = –10 V
5 V
C1
10 µ F
R OSC
1 M Ω
R OSC
1 M
Ω
+
C2
10 µ F
+
C1
10 µ F
+
C2
10 µ F
+
C4
10
µ
F
R RV
100 k Ω
to
1 M Ω
+
C3
10
µ
F
+
1
2
3
4
5
6
7
14
13
12
11
10
9
8
1
2
3
4
5
6
7
14
13
12
11
10
9
8
quired when any number of devices are connected in
parallel. Also, the voltage regulator in one chip is suffi-
cient to regulate the combined output.
