S1F78100Y Series
S1F70000 Series
EPSON 3–13
Technical Manual
S1F78100Y
Series
Note : Circuit Diagram for Measuring Supply Voltage Rejection Ratio Characteristic
f
in =50kHz
V DD
V DD
V SS
V O
C L I L
C L =10
µ
F I L =10mA
S1F78100Y Series
