S1F76620 Series
1–12 EPSON
S1F70000 Series
Technical Manual
Pad Center Coordinates (S1F76620D0A0)
Chip External Shape
Y
X +
(0,0)
2.60mm
2.30mm
Pad Assignment
Pad aperture : 100
µ
m
×
100
µ
m Chip thickness : 400
µ
m
Note
Do not bond the NC pad.
Pad No.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
Pad name
(NC)
(NC)
P OFF
(NC)
(NC)
(NC)
GND (V SS )
OSC1
OSC2
V DD
CAP1–
CAP1+
(NC)
V O
(NC)
(NC)
(NC)
Pad center
coordinates
X (
µ
m)
–984
984
Pad center
coordinates
Y (
µ
m)
1096
788
580
390
96
–218
–510
–802
–1094
–1134
–892
–514
182
372
750
942
1134
Description
—
—
Input pin for power off control
—
—
—
Power input pin (Minus side)
Oscillation resistor connection pin
Oscillation resistor connection pin
Power input pin (Plus side)
Pump up capacitor minus side connection pin for 2
times step-up
Pump up capacitor plus side connection pin for 2
times step-up
—
2 times step-up output pin
—
—
—
