S1F77200Y Series
5–2 EPSON
S1F70000 Series
Technical Manual
LINEUP
Table 5-1
Product
Voltage detectable
Output type
Output phase
Min. Typ. Max. Less than V DET V DET or above
S1F77210Y1C0 2.10 2.15 2.20 CMOS Low level High level
S1F77210Y1P0 2.20 2.25 2.30 CMOS Low level High level
S1F77210Y1S0 2.30 2.35 2.40 CMOS Low level High level
S1F77210Y1E0 2.50 2.55 2.60 CMOS Low level High level
S1F77210Y1F0 2.60 2.65 2.70 CMOS Low level High level
S1F77210Y1R0 2.73 2.80 2.87 CMOS Low level High level
S1F77210Y1G0 2.93 3.00 3.07 CMOS Low level High level
S1F77210Y1H0 3.13 3.20 3.27 CMOS Low level High level
S1F77210Y130 3.43 3.50 3.57 CMOS Low level High level
S1F77210Y1T0 3.90 4.00 4.10 CMOS Low level High level
S1F77210Y1M0 4.10 4.20 4.30 CMOS Low level High level
S1F77210Y1J0 4.30 4.40 4.50 CMOS Low level High level
S1F77210Y120 4.50 4.60 4.70 CMOS Low level High level
S1F77210Y1K0 4.70 4.80 4.90 CMOS Low level High level
S1F77210Y1L0 4.90 5.00 5.10 CMOS Low level High level
S1F77210Y2C0 2.10 2.15 2.20 CMOS High level Low level
S1F77210Y2F0 2.60 2.65 2.70 CMOS High level Low level
Product
Voltage detectable
Output type
Output phase
Min. Typ. Max. Less than V DET V DET or above
S1F77200Y1T0 3.90 4.00 4.10 N ch Open Drain Low level Hi–Z
S1F77200Y1F0 2.60 2.65 2.70 N ch Open Drain Low level Hi–Z
S1F77200Y1C0 2.10 2.15 2.20 N ch Open Drain Low level Hi–Z
S1F77200Y1N0 1.85 1.90 1.95 N ch Open Drain Low level Hi–Z
S1F77200Y1B0 1.10 1.15 1.20 N ch Open Drain Low level Hi–Z
S1F77200Y1Y0 1.05 1.10 1.15 N ch Open Drain Low level Hi–Z
S1F77200Y1A0 1.00 1.05 1.10 N ch Open Drain Low level Hi–Z
S1F77200Y1V0 0.90 0.95 1.00 N ch Open Drain Low level Hi–Z
S1F77220Y2D0 1.20 1.25 1.30 P ch Open Drain High level Hi–Z
Table 5-2
