S1F79100Y Series
S1F70000 Series
EPSON 3–25
Technical Manual
S1F79100Y
Series
Typical Performance Characteristics
S1F79100Y1B0
7.0
6.0
5.0
4.0
3.0
2.0
1.0
0.0
–40 –20 0 20 40 60 80 100
Ta [˚C]
I OPR
[
µ
A]
V I = 7V
6.0
5.0
4.0
3.0
2.0
1.0
0.0
0 –15 –10 –5
V I [V]
I OPR
[
µ
A]
Ta = 25˚C
I
O = 0mA
I OPR vs. Ta I OPR vs. V I
1.2
1.0
0.8
0.6
0.4
0.2
0.0
–40 –20 0 20 40 60 80 100
Ta [˚C]
|V
O
–V
I
| [V]
V I = 4.9V
I O = 50mA
I O = 10mA
0.8
0.7
0.6
0.5
0.4
0.3
0.2
0.1
0.0
0 10 20 30 40 50
I O [mA]
|V
I
–V
O
| [V]
Ta = 25˚C
V
I = –4.9V
|V O – V I | vs. Ta |V I – V O | vs. I O
