Epson Power Supply S1F70000 User Manual
Page 131
S1F79100Y Series
3–24
EPSON
S1F70000 Series
Technical Manual
S1F79100Y1P0
(V
DD
= 0V, Ta = –40
°
C to +85
°
C unless otherwise noted)
Parameter
Symbol
Conditions
Rating
Unit
Min.
Typ.
Max.
Input voltage
V
I
—
–15.0
—
—
V
Output voltage
V
O
V
I
= –6.0V, I
O
= 10mA
–4.10 –4.00 –3.90
V
Ta = 25
°
C
Operating current
I
OPR
V
I
= –4.0V to –15.0V
—
4.0
18.0
µ
A
Input/output voltage
|V
I
– V
O
|
V
I
= –4.0V, I
O
= 10mA
—
0.19
0.38
V
differential
Input voltage stabilization
∆
V
O
V
I
= –5.0V to –15V,
—
0.10
—
%/V
ratio
∆
V
I
• V
O
I
O
= 10mA, Isothermal
Output voltage drift
∆
V
O
V
I
= –7V,
—
40.0
—
mV
I
O
= 1mA to 30mA
S1F79100Y1B0
(V
DD
= 0V, Ta = –40
°
C to +85
°
C unless otherwise noted)
Parameter
Symbol
Conditions
Rating
Unit
Min.
Typ.
Max.
Input voltage
V
I
—
–15.0
—
—
V
Output voltage
V
O
V
I
= –7.0V, I
O
= 10mA
–5.10 –5.00 –4.90
V
Ta = 25
°
C
Operating current
I
OPR
V
I
= –5.0V to –15.0V
—
4.0
18.0
µ
A
Input/output voltage
|V
I
– V
O
|
V
I
= –5.0V, I
O
= 10mA
—
0.17
0.34
V
differential
Input voltage stabilization
∆
V
O
V
I
= –6.0V to –15.0V,
—
0.10
—
%/V
ratio
∆
V
I
• V
O
I
O
= 10mA, Isothermal
Output voltage drift
∆
V
O
V
I
= –7.0V,
—
50.0
—
mV
I
O
= 1mA to 50mA
