S1F70000 Series
EPSON 5–1
Technical Manual
S1F77200Y Series
S1F77200Y
Series
DESCRIPTION
The S1F77200Y series products are non-adjusting volt-
age detectors being developed utilizing he base of the
CMOS silicon gate process.
This voltage detector consists of the reference voltage
circuit, voltage comparator, hysteresis circuit and out-
put circuit, all operating on smaller current.
A voltage range to be detected is internally set on re-
spective detectors. A wide variety of our standard prod-
ucts are grouped as shown below according to the out-
put format employed for the voltage detector output pin.
The S1F77200Y series employs N-channel open drain
output approach. And the S1F77210Y series and S1F
77220Y series employ the CMOS output and P-channel
output, respectively.
The package used is the SOT89-3 pin plastic package.
Our voltage detectors are used for determining battery
life, and also for monitoring supply voltage fed to mi-
crocomputers and LSI systems.
FEATURES
• Full lineups: 19 types are prepared for the detection
range between 2.0V to 5.0V.
For the detection range from 0.8V to 2.5V, 7 types
are available (products designed for lower voltage
detection).
• Low operating current: Typ. 2.0
µ
A (V DD = 5.0V).
• Low operating voltage: 1.5V at minimum.
• Absolute maximum rated voltage: 15V maximum.
• Highly stable built-in reference voltage source: Typ.
1.0V.
• Better temperature characteristics of output voltage:
Typ. -100ppm/
°
C.
S1F77200Y Series CMOS Voltage Detectors
