Page 230: Appendix
S1F70000 Series
EPSON
6–7
Technical Manual
Appendix
Appendix
Dimension code
Dimensions (mm)
A
178
±
2.0
B
80
±
1.0
C
13.0
±
0.5
D
21.0
±
1.0
E
2.0
±
0.5
W
14.0 (See note.)
W1
1.5
±
0.1
W2
17 (See note.)
r
1.0
REEL SPECIFICATIONS
The reel specifications are shown in the following table
and figure. The reel is made of paperboard.
Note
W and W2 are measured at the reel core.
DEVICE POSITIONING
Small molded power IC devices are positioned as
shown in the following figure.
120˚
120˚
E
C
D
r
W
W
1
W
2
B A
T1
T2
