Selection Guide
2 EPSON
S1F70000 Series
Technical Manual
Product Features Package
• 6.00V positive output voltage regulator.
S1F78100Y2A0 • Low operating current (Typ. 3.0
µ
A). SOT89-3pin
• Input voltage stability (Typ. 0.1%/V).
• 5.00V positive output voltage regulator.
S1F78100Y2B0 • Low operating current (Typ. 3.0
µ
A). SOT89-3pin
• Input voltage stability (Typ. 0.1%/V).
• 4.50V positive output voltage regulator.
S1F78100Y2M0 • Low operating current (Typ. 3.0
µ
A). SOT89-3pin
• Input voltage stability (Typ. 0.1%/V).
• 4.00V positive output voltage regulator.
S1F78100Y2P0 • Low operating current (Typ. 3.0
µ
A). SOT89-3pin
• Input voltage stability (Typ. 0.1%/V).
• 3.90V positive output voltage regulator.
S1F78100Y2K0 • Low operating current (Typ. 3.0
µ
A). SOT89-3pin
• Input voltage stability (Typ. 0.1%/V).
• 3.50V positive output voltage regulator.
S1F78100Y2N0 • Low operating current (Typ. 3.0
µ
A). SOT89-3pin
• Input voltage stability (Typ. 0.1%/V).
• 3.30V positive output voltage regulator.
S1F78100Y2T0 • Low operating current (Typ. 3.0
µ
A). SOT89-3pin
• Input voltage stability (Typ. 0.1%/V).
• 3.20V positive output voltage regulator.
S1F78100Y2C0 • Low operating current (Typ. 3.0
µ
A). SOT89-3pin
• Input voltage stability (Typ. 0.1%/V).
Voltage regulator
Product Features Package
• Supply voltage conversion IC.
S1F76600M0B0
• It effectively converts input voltage V DD into –V DD or 2V DD
SOP4-8pin
S1F76600C0B0
• Output current : Max. 30mA at –5V
DIP-8pin
• Power conversion efficiency: Typ. 95%
• Supply voltage conversion IC.
• It effectively converts input voltage V DD into –V DD or 2V DD
S1F76620M0A0
• Output current : Max. 30mA at 5V
SOP4-8pin
• Power conversion efficiency: Typ. 95%
DC/DC Converter
Product Features Package
• On–chip voltage regulator.
S1F76610M0B0
• It effectively converts input voltage V DD into –V DD /–2V DD or 2V DD /3V DD
SOP5-14pin
S1F76610M2B0 • Output current : Max. 20mA at –5V SSOP2-16pin
S1F76610C0B0
• Power conversion efficiency: Typ. 95%
DIP-14pin
• Three temperature gradients for LCD panel power.
• On–chip voltage regulator.
S1F76540M0A0
• It effectively converts input voltage V DD into –2V DD /–3V DD /–4V DD.
SSOP2-16pin
• Low current Consumption : Typ. 130
µ
A at –5V, 4–time boosting
S1F76540C0A0
• Power conversion efficiency: Typ. 95%
DIP-16pin
• Three temperature gradients for LCD panel power.
• On–chip voltage regulator.
• It effectively converts input voltage V DD into 2V DD /3V DD /4V DD.
S1F76640M0A0 • Output current : Max. 20mA at 5V SSOP2-16pin
• Power conversion efficiency: Typ. 95%
• Three temperature gradients for LCD panel power.
DC/DC Converter and Voltage Regulator
