PACKAGE MARKINGS
The markings on S1F79100Y series device packages
use the following abbreviations.
Marking locations
Voltage regulator
code
Output voltage
code
FUNCTIONAL DESCRIPTIONS
Basic Operation
The S1F79100Y series uses a 3-pin series regulator
feedback loop. An operational amplifier compares
V
REG
from the voltage divider formed by R
1
and R
2
,
with V
REF
. The amplifier output adjusts the output
transistor gate bias to equalize the voltages and com-
pensate for fluctuations in V
I
.
V
REF
GND
V
O
R
1
V
REG
R
2
V
I
–
+
The following equation shows the relationship between
V
O
and V
REF
.
R
1
+ R
2
V
O
= ————— V
REF
R
1
Parameter
Code
Description
Output voltage code
B
5 V
D
3 V
Voltage regulator code
P
Positive
N
Negative
Note
The reflow furnace temperature profile requirements
must be satisfied during package reflow. Avoid solder-
ing on surface mount package (including SOT89) as it
causes a quick temperature change of package and a
device damage.
Internal Circuits
Reference voltage generator
The offset structure used in all three transistors results
in a high breakdown voltage that ensures a stable refer-
ence voltage output over a wide range of input voltages.
V
REF
V
1
V
SS
Enhancement
mode
Depletion
mode
Depletion
mode
