Epson Power Supply S1F70000 User Manual
Page 175
S1F76300 Series
4–30
EPSON
S1F70000 Series
Technical Manual
Device
Inductance (
µ
H)
Direct current (mA)
FL3H
0.22 to 10
280 to 670
FL4H
0.47 to 12
300 to 680
FL5H
10 to 1000
50 to 320
FL7H
680 to 8200
50 to 170
FL9H
330 to 33000
50 to 500
FL11H
10000 to 150000
35 to 110
Device
Rated current
Inductance (
µ
H) at 20kHz, 5V
Diameter
×
height
Wire gauge
I
DC
(A)
I
DC
= 0
I
DC
= rating
(mm-Max.)
(mmø)
HP011
1
200
160
0.5
HP021
2
65
55
20
×
12
0.7
HP031
3
30
23
0.8
HP012
1
600
450
0.5
HP022
2
180
135
22
×
13
0.7
HP032
3
120
80
0.8
HP052
5
45
30
1.0
HP013
1
1000
800
0.5
HP023
2
500
330
26
×
14
0.7
HP033
3
130
100
0.8
HP055
5
90
55
1.0
HP034S
3
400
250
0.8
HP054S
5
350
160
36
×
14
1.0
HP104S
10
50
30
1.6
HP024
2
1500
950
0.7
HP034
3
300
230
36
×
21
0.8
HP054
5
210
140
1.0
HP104
10
45
30
1.6
HP035
3
700
500
0.8
HP055
5
600
330
43
×
23
1.0
HP105
10
180
95
1.6
HP205
20
20
14
1.8
×
2 P
Drum coil inductors
Taiyo Yuuden FL series micro inductors
Toroidal coil inductors
Tohoku Metal Industries HP series toroidal coil inductors
