S1F76300 Series
4–24
EPSON
S1F70000 Series
Technical Manual
SPECIFICATIONS
Absolute Maximum Ratings
S1F76330 series
Parameter
Symbol
Rating
Unit
Input voltage
V
I1
7
V
Output current
I
O
100
mA
Output voltage
V
O
7
V
Power dissipation
P
D
200 (SOP)
mW
300 (DIP)
Operating temperature range
Topr
–30 to +85
˚C
Storage temperature range
Tstg
–65 to +150
˚C
Solding temperature (for 10 s). See note.
Tsol
260
˚C
Note
Temperatures during reflow soldering must remain within the limits set out in LSI Device Precautions. Never use
solder dip to mount S1F70000 series power supply devices.
Electrical Characteristics
S1F76330M1B0
V
SS
= 0V, Ta = 25 ˚C unless otherwise noted
Parameter
Symbol
Conditions
Rating
Unit
Min. Typ. Max.
Input voltage
V
I1
V
O
> V
I2
0.9
—
2.0
V
Output voltage
V
O
V
I1
= 1.5V
2.90 3.00 3.10
V
V
I1
= 1.5V,
Operating current
I
DDO
f
CLK
= 32kHz,
—
5
30
µ
A
I
O
= 1.0mA
Standby current
I
DDS
V
I1
= 1.5V
—
3
10
µ
A
Switching transistor ON resistance
R
SWON
V
I1
= 1.5V, V
O
= 3.0V,
—
6
12
Ω
V
SW
= 0.2V
Switching transistor leakage current
I
SWQ
V
I1
= 1.5V, V
O
= 1.5V,
—
—
0.5
µ
A
V
SW
= 7.0V
CL
O
Low-level output current
I
OL
V
I1
= 1.5V, V
O
= 3.0V,
0.5
1.0
—
µ
A
V
OL
= 0.2V
CL
O
High-level output current
I
OH
V
I1
= 1.5V, V
O
= 3.0V,
0.55 1.1
—
µ
A
V
OH
= 0.2V
PS pull-up current
I
IH
V
IH
= 1.5V
—
—
0.5
µ
A
Oscillator start-up voltage
V
STA
0.9
—
—
V
Oscillator shut-down voltage
V
STP
—
—
0.9
V
C
G
= 10pF, C
D
= 10pF,
R
D
= 300k
Ω
,
f
OSC
= 32kHz
