S1F76640 Series

S1F70000 Series

EPSON

2–57

Technical Manual

S1F76640

Series

APPLICATION EXAMPLE

2 Times Step-up, 3 Times Step-up and 4 Times Step-up

Figure 8.1 shows the connection for getting 4 times step-up output of an input voltage by operating the step-up
circuit only. In case of 3 times step-up, the capacitor C

3

is removed and CAP3+ (Pin No. 14) is short-circuited to

V

O

(Pin No. 15), and 3 times step-up voltage is obtained from V

O

(CAP3+). In case of 2 times step-up, the capacitor

C

2

is also removed and CAP2+ (Pin No. 13) is short-circuited to V

O

(Pin No. 15), and 2 times step-up voltage (10V)

is obtained from V

O

(CAP2+).

Figure 8-1 4 times step-up circuit

4 Times Step-up + Stabilization Circuit

Figure 8-2 shows an application example for stabilizing step-up outputs obtained in 8-(1) through the stabilization
circuit and for providing temperature gradient to V

REG

output by means of the temperature gradient selection cir-

cuit. In this application example, both outputs from V

O

and V

REG

can be indicated at the same time. Also,

operation of 3 times step-up + stabilization circuit is possible by using the 3 times step-up operation mentioned in 8-
(1), and operation of 2 times step-up + stabilization circuit is possible by using the 2 times step-up operation.

Figure 8-2 Operation of 4 Times Step-up + Stabilization Circuit (Temperature Gradient CT1 is

selected.)

Note 1 :

Since input impedance at the RV pin (No. 1) is high, it is necessary to use a shielded wire as a measure
against noise in case of a long connection. It is also effective to make the R

RV

value small for reducing

noise influence. (In this case, however, more current comes to be consumed at R

RV

.)

C

1

V

I

C

2

C

3

C

4

4V

I

+

+

+

+

RV

V

REG

TC1

TC2

P

OFF

V

SS

OSC1

OSC2

1

2

3

4

5

6

7

8

16

15

14

13

12

11

10

9

V

RI

V

O

CAP3+

CAP2+

CAP2–

CAP1+

CAP1–

V

DD

RV

V

REG

TC1

TC2

P

OFF

V

SS

OSC1

OSC2

1

2

3

4

5

6

7

8

16

15

14

13

12

11

10

9

V

RI

V

O

CAP3+

CAP2+

CAP2–

CAP1+

CAP1–

V

DD

C

2

C

5

+

C

1

+

C

3

+

C

4

V

I

R

1

R

1

R

1

+R

2

R

2

+

+

Note 1

V

REG

= ·V

RV

V

REG

(R

RV

=R

1

+R

2

)

Note 2
