S1F76300 Series
4–18
EPSON
S1F70000 Series
Technical Manual
Drum coil inductors
Taiyo Yuuden FL series micro-inductors
Toroidal coil inductors
Tohoku Metal Industries HP series toroidal coil inductors
Device
Inductance
Direct current (mA)
FL3H
0.22
µ
H to 10
µ
H
280 to 670
FL4H
0.47
µ
H to 12
µ
H
300 to 680
FL5H
10
µ
H to 1mH
50 to 320
FL7H
680
µ
H to 8.2mH
50 to 170
FL9H
330
µ
H to 33mH
50 to 500
FL11H
10mH to 150mH
35 to 110
Device
Rated current I
DC
Inductance (
µ
H) at 20kHz, 5V
Diameter
×
height
Wire gauge
(A)
I
DC
= 0
I
DC
= rating
(mm-Max.)
(mmø)
HP011
1
200
160
0.5
HP021
2
65
55
φ
20
×
12
0.7
HP031
3
30
23
0.8
HP012
1
600
450
0.5
HP022
2
180
135
φ
22
×
13
0.7
HP032
3
120
80
0.8
HP052
5
45
30
1.0
HP013
1
1000
800
0.5
HP023
2
500
330
φ
26
×
14
0.7
HP033
3
130
100
0.8
HP055
5
90
55
1.0
HP034S
3
400
250
0.8
HP054S
5
350
160
φ
36
×
18
1.0
HP104S
10
50
30
1.6
HP024
2
1500
950
0.7
HP034
3
300
230
φ
36
×
21
0.8
HP054
3
210
140
1.0
HP104
10
45
30
1.6
HP035
3
700
500
0.5
HP055
5
600
330
φ
43
×
23
1.0
HP105
10
180
95
1.6
HP205
20
20
14
1.8
×
2 P
