Super Systems Inc. Page 197 of 201 Configurator Manual #4562 Rev D
Controller Source
Location
Write
Register Read
Scale Writ
e
Scale Description
Carbpro 3.0 Events 8 43 1 1 Events Actual
(MMI Mode) 2 17 1 1 Events Setpoint
8 43 1 1 Events Input
Controller Source
Location
Write
Register Read
Scale Writ
e
Scale Description
Eurotherm 2500 19 19 8 8 PV
(Modbus Mode) 5 5 1 1 Setpoint Loop 1
40 40 1 1 Percent Output Loop 1
Controller Source
Location
Write
Register Read
Scale Writ
e
Scale Description
SSi_8_8 5 100 1 1 Events Actual
3 98 1 1 Events Setpoint
6 101 1 1 Events Input
Controller Source
Location
Write
Register Read
Scale Writ
e
Scale Description
Series 9200 5 176 1 1 Events Actual
2 109 1 1 Events Setpoint
4 175 1 1 Events Input
Controller Source
Location
Write
Register Read
Scale Writ
e
Scale Description
Micrologix Modbus 10 110 1 1 Events Actual
RS-232 0 100 1 1 Events Setpoint
15 115 1 1 Events Input
Controller Source
Location
Write
Register Read
Scale Writ
e
Scale Description
MCMModule Modbus 10 110 1 1 Events Actual
RS-232 0 100 1 1 Events Setpoint
15 115 1 1 Events Input
