QS300 -2 LogBook/300 Quick Start Guide
LogBook/300 Quick Start
Software Installation …… QS300 -2
Hardware Connection ……
QS300
-2
Hardware Configuration …… QS300 -4
LogBook/300 Device Configuration …… QS300 -5
Testing the Hardware ……
QS300
-7
Acquisition Configuration …… QS300 -8
A Note about Calibration …… QS300 -8
Before you get started
Verify that you have the following items.
LogBook/300
TR-40U Power Supply
Serial/Parallel Patch Cable, or PC Card Reader
PC with ECP (Enhanced Capabilities Port)
Data Acquisition CD
Monitor: SVGA, 1024 x 768 screen resolution
Windows 2000 SP4 and Windows XP users:
PC with I ntel ™ Pentium [or equivalent], 1 GHz;
512
MB memory; 10 GB disk space
Windows Vista users:
PC must be Windows Vista Premium Ready
Software Installation
1. Close all running applications on the host PC.
2. Remove previous version drivers, if present. You can do this through Microsoft’s Add/Remove Programs
feature.
3. Insert the Data Acquisition CD (8.1.2 or higher) into your CD-ROM drive and wait for the PC to auto-run. An
Opening Screen will appear. If AutoRun is disabled: (a) right click Windows Start menu, (b) select Explore; and
(c) double-click MasterSetup.exe. As an alternative to using the CD, you can download software from:
www.mccdaq.com/products/software.aspx
4. Click the <ENTER SETUP> button.
Note: If you are downloading software from our website, follow instructions provided there.
5. From the hardware selection screen, select your data acquisition device then follow the on-screen instructions.
Note: To enable all LogView features:
(a) From LogView’s main window, open the File pull-down menu,
(b) select Authorization,
(c) enter ED7B55484273 in the dialog box and apply the code.
Hardware Connection
WARNING
Electric shock hazard. Turn off power to all system-connected devices prior to connecting
or disconnecting cables, or setting hardware configurations. Failure to do so could result
in electric shock or death, and equipment damage, even under low-voltage conditions.
When using LogBook/300 in attached mode, the PC-Card [in LogBook/300] must already
have the file
logbook.sys.
Otherwise, LogView cannot communicate with LogBook/300,
and LogBook/300 will appear dead.
IMPORTANT! Software must be installed first!
