MDE-4363F Atlas™ Fuel Systems Owner’s Manual · September 2011 Page 45
Operating Sequence for Series 9800 Only The Atlas Fuel System
• A pulser error is detected (electronic unit only).
• A time-out is reached (if the unit is programmed with a time out value). If connected to a
fuel management system, the time-out loaded into the system will be used (commercial
electronic only). The unit will turn off if it is idle for a preprogrammed time when no fuel
is flowing.
• (9800 models) A quantity of 990.000 gallons (9900.00 liters) is reached. If connected to a
fuel management system, the limit set in the system will be used.
• The pump is halted by an operator of a fuel management system.
• An AC power failure occurs.
• Station Emergency Stop button is pressed.
• Calibration error (DEF or E85 units only)
Standalone Mode Error Handling (Series 9800)
When operating the pump/dispenser in the standalone mode (not connected to a fuel
management system), the Atlas displays two or three digit error transaction codes on the LCD
displays when transactions are terminated abnormally (by a means other than turning off the
pump handle).
The possible error conditions that may be displayed are listed in the following table.
The error codes are displayed for two seconds at the left of the LCD window, alternating with
a five-second display of the last sale amount. The display alternates between the two until a
new transaction begins (In the case of a 993, new transaction will NOT start until the error is
cleared.). When an error occurs, the user must note the error code and relay the information to
the ASC.
Transaction error codes are displayed only when the pump/dispenser is operating in standalone
mode. When connected to a fuel management system, (on-line mode), transaction error codes
are transmitted back to the fuel management system with the completed transaction data.
Calibration for 9850 Only
All Gasboy pumps and remote dispensers are adjusted for accurate measure at the factory.
However, since the conditions of the installation can affect pump accuracy, it is the
responsibility of the installer to inspect the pump for accuracy and make the required
adjustments. When required, it is the owner’s responsibility to report this device to the local
Weights and Measures officials for their inspection before the unit is put into service.
Calibration methods are given in gallons. When calibrating liter pumps, the same procedure is
used, but gallons is converted to liters (1 gallon = 3.78 liters, 1 gallon = 0.83267 US Imperial
gallons).
Code Condition
55 Power failure
56 Pulser error
57 Timed out
58 Limit cutoff
59 9840 Only - Flow error unit 1
60 9840 Only - Flow error unit 2
993 9860 or 9870 Only - Calibration error
