The Atlas Fuel System
Pump/Dispenser Components
Page 8
MDE-4363F Atlas™ Fuel Systems Owner’s Manual · September 2011
The external components of a Gasboy Atlas pump/dispenser (Electronic Retail Unit) are
shown in
. Electronic units have digital displays as opposed to mechanical displays.
In units that are Electronic Commercial instead of Retail, the external components are almost
the same with the exception that there are only totalizers, PPU, and the main display showing
the gallons pumped.
Figure 3-2: Atlas Electronic Retail Unit
Boot Area
Digital Main
Display
Gallons Display
PPU
Gasboy Atlas Logo
Door Lock
Access Door
Nozzle and
Pump Handle
Control Lever
Electro-mechanical
Totalizer
Electronic Retail Unit
