Comtech EF Data SFC1800A User Manual
Page 98
Appendix B
SFC1800A Synthesized Frequency Upconverter
B-6
TM111 – Rev. 1.0
Bit 0 = RF Dtect Fault
Bit 1 = IF Dtect Fault
Bit 2-7 = Spares
0 = Pass, 1 = Fail"
::= { radConverterStatus 12 }
radConverterICCAddress OBJECT-TYPE
SYNTAX
INTEGER (1..255)
MAX-ACCESS
read-only
STATUS
current
DESCRIPTION
" "
::= { radConverterStatus 13 }
radConverterICCType OBJECT-TYPE
SYNTAX
INTEGER (0..255)
MAX-ACCESS
read-only
STATUS
current
DESCRIPTION
"A bit field that shows converter ICC type. On startup, the agent
initializes this to the value '00000000'B.
Bit 0-3 = Band
Down-Band: 0 through 5
0=Normal C-Band, 1=Extended C-Band, 2=Normal Ku-
Band,
3=Normal American Ku-Band, 4=India High C-Band,
5=European Ku-Band
Up-Band: 0 through 4
0=Normal C-Band, 1=Extended C-Band, 2=Normal Ku-
Band,
3=Normal Ku-Band, 4=India High C-Band
Bit 4-5 = Spare
Not Used
Bit 6 = Normal_Custom
0=Normal, 1=Custom
Bit 7 = Down_Up
0=Down, 1=Up"
::= { radConverterStatus 14 }
-- --------------------------------------------------------------------------------------------------------------------
-- --------------------------------------------------------------------------------------------------------------------
-- Converter Switch non-volatile status information.
radConverterSwitchBackupMode OBJECT-TYPE
SYNTAX
INTEGER {
manual(1),
auto_nonrevertive(2),
auto_revertive(3)
}
MAX-ACCESS
read-write
STATUS
current
DESCRIPTION
"Selects MANUAL or AUTOMATIC backup modes.
Manual: A Prime Converter can be backed up through manual control only.
Auto-Nonrevertive: A Prime Converter will be backed up if it fails.
It will remain backed up until it is manually unbacked.
Auto-Revertive: A Prime Converter will be backed up if it fails.
If a second Converter of a higher priority (see 7. below) fails, the
Switch will unback the first and backup the second Converter. Also,
if the first Converter recovers after it has been backed up (i.e., no
longer has a fault), the switch will unback it and place it online again."
::= { radConverterSwitchNVStatus 1 }
radConverterSwitchLearn OBJECT-TYPE
SYNTAX
PrimeControlType
MAX-ACCESS
read-write
STATUS
current
DESCRIPTION
