SFC1800A Synthesized Frequency Upconverter
Appendix B
TM111 – Rev. 1.0
B-
11
For Upconverter:
Channel: cc
{cc = current channel number, 01 to 30}
Frequency: ffff.fff
{ffff.fff = frequency in MHz}
Gain: sgg.g
{s = ± and gg.g = gain in dB}
RSS: nn
{n = current Received Signal Strength}
Stored Faults:
{None/Signal Fault/LO Fault/LO Fault, Signal Fault}
Reference:
{Internal/External}
{End of transmission}
C.8 Set Channel Command (S, P1:1, P1:8)
This command changes the Current Channel and thus the Gain and Frequency of the converter
to one of the 30 preprogrammed channels. The command is as follows:
@01/SETCHANcc
Where ‘cc’ represents a channel number from 01 - 30.
If successful, the converter will return the following string:
For Upconverter:
Channel: cc
{cc = current channel number, 01 to 30}
Frequency: ffff.fff
{ffff.fff = frequency in MHz}
Gain: sgg.g
{s = ± and gg.g = gain in dB}
Input Atten: aa dB
{aa = input attenuation}
RF:
{Off/On}
Stored Faults:
{None/Signal Fault/LO Fault/LO Fault, Signal Fault}
Reference:
{Internal/External}
{End of transmission}
For Upconverter:
Channel: cc
{cc = current channel number, 01 to 30}
Frequency: ffff.fff
{ffff.fff = frequency in MHz}
Gain: sgg.g
{s = ± and gg.g = gain in dB}
RSS: nn
{n = current Received Signal Strength}
Stored Faults:
{None/Signal Fault/LO Fault/LO Fault, Signal Fault}
Reference:
{Internal/External}
{End of transmission}
