SFC1800A Synthesized Frequency Upconverter Appendix A
TM111 – Rev. 1.0 A -7
A.4 Converter Commands
Opcode: <2201h>
Command control mode
<1> Mode 0 = Local, 1 = Terminal, 2 = Remote, 3 = Ethernet
Opcode: <2C04h>
Command set time
<1>
<1>
<1>
Hour
<1>
<1> 0 – 23
0 – 59
0 – 59
Opcode: <2C05h>
Query set date
<1>
<1>
<1>
Year
Month
Day 0 – 99
0 – 11
0 – 30
Opcode: <2C06h>
Command set time and date
<1>
<1>
<1>
<1>
<1>
<1>
Year
Month
Day
Hour
Minute
Second 0 – 99
0 – 11
0 – 30
0 – 23
0 – 59
0 – 59
Opcode: <2C03h>
Command clear latched alarms
(No Command Data)
Opcode: <3010h>
Command set frequency for the current channel
<4> Frequency Binary value in 125 kHz steps
Opcode: <3011h>
Command set gain for the current channel
<4> Gain -20.0 dB to +30.0 dB depending on input attenuator setting
Opcode: <3012h>
Command set frequency for the given channel
<4>
<1>
Frequency
Channel Binary value in 125 kHz steps
1 - 30
