SFC1800A Synthesized Frequency Upconverter Technical Specifications
TM111 – Rev. 1.0 7-3
7.6.1 Converter Settings
Monitored and/or controlled from
Frequency
the Front Panel or remotely, using Channel Gain
the RS-232/RS-485 or Ethernet The Current Channel
remote port: Gain Offset
Event Buffer
Faults Status and Mask
Power Supply Voltages
Frequency Reference Status and Offset Control
Input Attenuation
Remote Protocol
Baud, Line, and Echo Modes
Carrier Control and Status
Converter Band and User Minimum/Maximum
Frequencies
Converter and Frequency Type
Terminal Emulation and Baud Rate
RF Detector
IF Detector and DAC Attenuation Voltages
7.6.2 Switch Settings
Monitored and/or controlled from
Priority
the Front Panel or remotely using All Available Prime Summary Fault
the RS-232/RS-485 or Ethernet Fault Delay
remote port (backup only): All Available Prime Learn Status
Force Backup
All Available Prime Backup Test Status
Learn Control
All Available Prime Configuration Change Status
Backup Testing
All Available Prime Relay Status
Compensation Control
All Available Prime Converter Types
7.6.3 LED Indicators
Standby
LO Fault
Signal Fault
External Reference Online
Backup
Software Fault
Manual (Backup Only)
Power
Fault
Event
Remote
