Appendix B
SFC1800A Synthesized Frequency Upconverter
B-2
TM111 – Rev. 1.0
-- -------------------------------------------------------------------------------------------------------------------
-- -------------------------------------------------------------------------------------------------------------------
-- Textual Conventions
ControlType ::= TEXTUAL-CONVENTION
STATUS
current
DESCRIPTION
"Represents a boolean control value."
SYNTAX
INTEGER { disable(1), enable(2) }
InversionType ::= TEXTUAL-CONVENTION
STATUS
current
DESCRIPTION
"Represents a boolean inversion value."
SYNTAX
INTEGER { normal(1), inverted(2) }
AlarmByteType ::= TEXTUAL-CONVENTION
STATUS
current
DESCRIPTION
"Represents a one byte integer value. Limits are 0 to 255"
SYNTAX
INTEGER (0..255)
PrimeStatusType ::= TEXTUAL-CONVENTION
STATUS
current
DESCRIPTION
"Represents a one byte integer value. Limits are 0 to 255
Bit0 = Prime1 status
Bit1 = Prime2 status
Bit2 = Prime3 status
Bit3 = Prime4 status
Bit4 = Prime5 status
Bit5 = Prime6 status
Bit6 = Prime7 status
Bit7 = Prime8 status "
SYNTAX
INTEGER (0..255)
PrimeControlType ::= TEXTUAL-CONVENTION
STATUS
current
DESCRIPTION
"Represents a prime control setup. Limits are 1 to 9
1 = Prime1
2 = Prime2
3 = Prime3
4 = Prime4
5 = Prime5
6 = Prime6
7 = Prime7
8 = Prime8
9 = All Primes"
SYNTAX
INTEGER (1..9)
-- -------------------------------------------------------------------------------------------------------------------
-- -------------------------------------------------------------------------------------------------------------------
-- Converter non-volatile status information.
radConverterFrequency OBJECT-TYPE
SYNTAX
INTEGER (50000000..90000000)
MAX-ACCESS
read-write
STATUS
current
DESCRIPTION
"Selects RF input frequency in 125 KHz steps.
3.62 GHz to 4.20 GHz SFC4200 C-Band Down Converter
5.845 GHz to 6.425 GHz SFC6400 C-Band Up Converter
10.95 GHz to 12.75 GHz SFC 1275 Ku-Band Down Converter
14.00 GHz to 14.50 GHz SFC 1450 Ku-Band Up Converter"
::= { radConverterNVStatus 1 }
radConverterChannelGain OBJECT-TYPE
SYNTAX
INTEGER (-200..300)
MAX-ACCESS
read-write
STATUS
current
