SFC1800A Synthesized Frequency Upconverter
User Interfaces
TM111 – Rev. 1.0
4-11
TIMEOUT:
{00 - 99}
Allows the user to set the length of inactive time (in
seconds) after which the display backlight shuts off
automatically. Entering 00 allows the backlight to remain
on continuously.
KEY CLICK:
{OFF, ON}
Allows the user turn an audible key click on/off.
TERMINAL:
TERM. BAUD:
{2400, 9600, 19200}
Allows the user to set the baud rate for terminal port
communication.
EMULATION:
{ADDS VP, VT100, WYSE 50}
Allows the user to set the terminal emulation mode.
ECHO MODE:
{OFF, ON}
Allows the user to control whether the input at the
terminal is echoed back.
REMOTE PORT:
REMOTE PRTOCOL:
{ASCII, RLLP}
Allows the user to set the remote port communication
protocol.
REMOTE ADDR:
{32 - 255 RLLP, 1 – 255 ASCII}
Allows the user to set the communication address of the
remote port.
REMOTE BAUD:
{2400, 9600, 19200}
Allows the user to set the baud rate for remote port
communication.
ECHO MODE:
{OFF, ON}
Allows the user to control whether the input at the
terminal is echoed back. Only valid in Remote ASCII
Mode.
REMOTE LINE:
{RS-232, RS-485}
Sets the interface type of the remote port.
HW/FW CONFIG:
FIRMWARE:
FW/XXXX - - Version Y.YY
Displays the revision number of the installed M&C
Firmware (where XXXX is the firmware number and
Y.YY is the version).
FW/XXXX - - 19DEC2002
Displays the revision number and release date of the
installed M&C Firmware.
