Appendix B SFC1800A Synthesized Frequency Upconverter
B-14 TM111 – Rev. 1.0
SYNTAX AlarmByteType
MAX-ACCESS read-only
STATUS current
DESCRIPTION
"A bit field. On startup, the agent initializes this
to the value '00000000'B.
Bit 0 = CPLD test fault
Bit 1 = FPGA test fault
Bit 2 = Eeprom test fault
Bit 3-7 = Spares
0 = Pass, 1 = Fail"
::= { radConverterCommonStatus 3 }
radConverterCommonLatchedMinorAlarmStatus OBJECT-TYPE
SYNTAX AlarmByteType
MAX-ACCESS read-only
STATUS current
DESCRIPTION
"A bit field. On startup, the agent initializes this to
the value '00000000'B.
Bit 0 = VCC1 fault
Bit 1 = +9V fault
Bit 2 = +15V fault
Bit 3 = -15V fault
Bit 4 = Reference activity fault
Bit 5-7 = Spares
0 = Pass, 1 = Fail"
::= { radConverterCommonStatus 4 }
radConverterCommonUserMinFrequency OBJECT-TYPE
SYNTAX INTEGER (3620000..14750000)
MAX-ACCESS read-only
STATUS current
DESCRIPTION
"User minimum frequency."
::= { radConverterCommonStatus 5 }
radConverterCommonUserMaxFrequency OBJECT-TYPE
SYNTAX INTEGER (3620000..14750000)
MAX-ACCESS read-only
STATUS current
DESCRIPTION
"User maximum frequency."
::= { radConverterCommonStatus 6 }
radConverterCommonSynthesizerType OBJECT-TYPE
SYNTAX INTEGER {
mfs1191(1),
mfs448(2),
mfs459(3),
mfs544(3),
mfs881(4),
mfs474(5),
mfs4_47(6),
mfs4_59(7)
}
MAX-ACCESS read-write
STATUS current
DESCRIPTION
"Shows the currently used synthesizer:
MFS 1191:IF LO= 1.7 GHz, Low range = 11.91GHz, High range = 12.73 GHz
MFS 448:IF LO= 1.225 GHz, Low range = 4.48 GHz, High range = 5.355 GHz
MFS 459:IF LO= 1.1125 GHz, Low range = 4.5925 GHz, High range = 5.2425 GHz
MFS 544:IF LO= 1.1125 GHz, Low range = 5.4475 GHz, High range = 5.8675 GHz
MFS 881:IF LO= 2.0 GHz, Low range = 8.81 GHz, High range = 10.68 GHz
MFS 474:IF LO= 1.1125 GHz, Low range = 4.74 GHz, High range = 5.54 GHz
