SFC1800A Synthesized Frequency Upconverter Appendix B
TM111 – Rev. 1.0 B- 13
serial interface"
::= { radConverterCommonNVStatus 9 }
radConverterCommonMajorAlarmMask OBJECT-TYPE
SYNTAX AlarmByteType
MAX-ACCESS read-write
STATUS current
DESCRIPTION
"Major Alarm mask:
Bit 0 = CPLD test fault
Bit 1 = FPGA test fault
Bit 2 = Eeprom test fault
Bit 3-7 = Spares
0 = Mask, 1 = Allow"
::= { radConverterCommonNVStatus 10 }
radConverterCommonMinorAlarmMask OBJECT-TYPE
SYNTAX AlarmByteType
MAX-ACCESS read-write
STATUS current
DESCRIPTION
"Minor Alarm mask:
Bit 0 = VCC1 fault
Bit 1 = +9V fault
Bit 2 = +15V fault
Bit 3 = -15V fault
Bit 4 = Reference activity fault
Bit 5-7 = Spares
0 = Mask, 1 = Allow"
::= { radConverterCommonNVStatus 11 }
-- --------------------------------------------------------------------------------------------------------------------
-- --------------------------------------------------------------------------------------------------------------------
-- Converter common status information.
radConverterCommonMajorAlarmStatus OBJECT-TYPE
SYNTAX AlarmByteType
MAX-ACCESS read-only
STATUS current
DESCRIPTION
"A bit field. On startup, the agent initializes this
to the value '00000000'B.
Bit 0 = CPLD test fault
Bit 1 = FPGA test fault
Bit 2 = Eeprom test fault
Bit 3-7 = Spares
0 = Pass, 1 = Fail"
::= { radConverterCommonStatus 1 }
radConverterCommonMinorAlarmStatus OBJECT-TYPE
SYNTAX AlarmByteType
MAX-ACCESS read-only
STATUS current
DESCRIPTION
"A bit field. On startup, the agent initializes this to
the value '00000000'B.
Bit 0 = VCC1 fault
Bit 1 = +9V fault
Bit 2 = +15V fault
Bit 3 = -15V fault
Bit 4 = Reference activity fault
Bit 5-7 = Spares
0 = Pass, 1 = Fail"
::= { radConverterCommonStatus 2 }
radConverterCommonLatchedMajorAlarmStatus OBJECT-TYPE
