C.2 Status Command (All)
This command returns the current status of the converter. The command is as follows:
@01/STATUS
A single converter will return the following string of information:
For Upconverter:
Configuration: Single
Status:
{Offline, Warming up/Offline/Setup/Online}
Channel: cc
{cc = current channel number, 01 to 30}
Frequency: ffff.fff
{ffff.fff = frequency in MHz}
Gain: sgg.g
{s = ± and gg.g = gain in dB}
Input Atten: aa dB
{aa = input attenuation}
RF:
{Off/On}
Stored Faults:
{None/Signal Fault/LO Fault/LO Fault, Signal Fault}
Reference:
{Internal/External}
{End of transmission}
For Upconverter:
Configuration: Single
Status:
{Offline, Warming up/Offline/Setup/Online}
Channel: cc
{cc = current channel number, 01 to 30}
Frequency: ffff.fff
{ffff.fff = frequency in MHz}
Gain: sgg.g
{s = ± and gg.g = gain in dB}
RSS: aa dBm
{aa = received signal strength}
Stored Faults:
{None/Signal Fault/LO Fault/LO Fault, Signal Fault}
Reference:
{Internal/External}
{End of transmission}
A prime converter in a 1:1 Switch Configuration will return the following string of information:
Converter Configuration: One for One Primary
Switch Configuration:
{Manually Selected/Manually De-Selected/Auto}
Status:
{Faulted, Offline, Warming up/Faulted,
Offline/Setup/Online/Standby}
Channel: cc
{cc = current channel number, 01 to 30}
Frequency: ffff.fff
{ffff.fff = frequency in MHz}
Gain: sgg.g
{s = ± and gg.g = gain in dB}
Input Atten: aa dB
{aa = input attenuation}
RF:
{Off/On}
Stored Faults:
{None/Signal Fault/LO Fault/LO Fault, Signal Fault}
Reference:
{Internal/External}
{End of transmission}
