Setup
ATCA-9405 Installation and Use (6806800M71G) 55
2.4.3 Hot Swap
The ATCA-9405 can be Hot Swapped, as defined in the ATCA specification. This section
describes how to insert and extract an ATCA-9405 module in a typical ATCA system. (These
procedures assume the system is using a shelf manager.)
Inserting a board
1. Insert the ATCA-9405 into an available slot.
2. Push the face plate handle (tab).
The blue Hot Swap LED on the front panel (see Figure 2-1 ) flashes a long blink to indicate that
the board insertion is in progress and the system management software is activating the slot.
Then the blue LED turns off, indicating the insertion process is complete, and payload power is
present.
The ATCA-9405 Rear Transition Module (RTM) has its own Hot Swap LED and switch, and it
can be Hot Swapped in/out independently of the face plate. If the face plate is not present,
then the RTM will not be powered. If the face plate is Hot Swapped out, the blue LED of the
RTM illuminates. In either case, the RTM can be safely removed.
Personal Injury or Product Damage
The product is supplied by a TNV-2 voltage. This voltage is considered hazardous. Make sure
that the external power supply meets the relevant safety standards.
Make sure that TNV-2 is separated from dangerous voltages (mains) through double or
reinforced insulation.
