Setup

ATCA-9405 Installation and Use (6806800M71G)

40

2.3.3.1.3

Serial Console Ports

Three shielded RJ45 connectors (with Cisco style pin-out) for serial consoles are available at the
front panel.

Table 2-9 Serial Console Connector Pin-out (Cisco Style)

Pin

Signal

1

RTS#

2

NC

3

TXD

4

GND

5

GND

6

RXD

7

NC

8

CTS#
