Supported IPMI Commands
ATCA-7365-CE Installation and Use (6806800L73J)
240
8.3.1
Serial Output Commands
8.3.1.1
Set Serial Output Command
The Set Serial Output command selects the serial port output source for a serial port
connector.
8.3.1.1.1 Request Data
The following table lists the request data applicable to the Set Serial Output command.
Table 8-19 Serial Output Commands
Command Name
NetFn (Request/Response)
CMD
Description
Set Serial Output
0x2E/0x2F
0x15
Get Serial Output
0x2E/0x2F
0x16
Table 8-20 Request Data of Set Serial Output Command
Byte
Data Field
1
LSB of Artesyn Embedded Technologies IANA Enterprise number. A value of 0xCD has
to be used.
2
Second byte of Artesyn Embedded Technologies IANA Enterprise number. A value of
0x65 has to be used.
3
MSB of Artesyn Embedded Technologies IANA Enterprise number. A value of 0x00 has
to be used.
4
Serial connector type
0: Face plate connector
1: Backplane connector
All other values are reserved.
Note: Only the faceplate connector is supported. No connector on the RTM available.
5
Serial connector instance number. A sequential number that starts from "0".
