Maps and Registers
ATCA-7365-CE Installation and Use (6806800L73J) 187
Note: For LPC I/O address 0x80 is used.
6.4.3 Module Identification Register
The Module Identification Register identifies the ATCA-7365 Blade (Wellbeck).
0x45 x x SFMEM Module Configuration Register
0x48 x x Update Channel Equalization Control
0x49 x - IPMC E-Keying Status Register
0x4A x x IPMC E-Keying Control Register
0x4B x - IPMC GPIO Register
0x50 x x LED Status and Control Register
0x58 x x NMI Status and Control Register
0x60 -0x66 x - Telecom Clocking Registers
0x6F x x Miscellaneous Status/Control Register
0x7D x x LPC Scratch Register
0x7E x x IPMC Scratch Register
0x7F x x POST codes from host
1. For LPC I/O accesses add the LPC I/O Base Address 0x600
Table 6-40 FPGA Register Map Overview (continued)
Address
Offset
1
LPC I/O
IPMC
SPI
Description
Table 6-41 Module Identification Register
Address Offset: 0x00
Bit Description Default Access
7:0 ATCA-7365 Blade (Wellbeck) Module Identification 0x60 r
