Transceiver Reconfiguration Controller Connectivity for Designs Using
CvP
If your design meets the following criteria:
• It enables CvP
• It includes an additional transceiver PHY that connect to the same Transceiver Reconfiguration
Controller
then you must connect the PCIe
refclk
signal to the
mgmt_clk_clk
signal of the Transceiver Reconfigu‐
ration Controller and the additional transceiver PHY. In addition, if your design includes more than one
Transceiver Reconfiguration Controller on the same side of the FPGA, they all must share the
mgmt_clk_clk
signal.
For more information about using the Transceiver Reconfiguration Controller, refer to the Transceiver
Reconfiguration Controller chapter in the Altera Transceiver PHY IP Core User Guide.
Related Information
• Altera Transceiver PHY IP Core User Guide
• Application Note 645: Dynamic Reconfiguration of PMA Controls in Stratix V Devices
