Altera 100G Interlaken MegaCore Function User Manual
Page 75
Signal Name
Direction
Width
(Bits)
Description
reconfig_address
Input
14 or 15 Address to access the hard PCS registers. This signal
holds both the hard PCS register offset and the
transceiver channel being addressed, in the following
fields:
• [8:0]: register offset in the hard PCS
• [N:9]: Interlaken lane number
• In 12-lane variations, N is 13
• In 24-lane variations, N is 14
reconfig_readdata
Output
32
After user logic asserts the
reconfig_read
signal,
when the IP core deasserts the
reconfig_
waitrequest
signal,
reconfig_readdata
holds valid
read data.
reconfig_waitrequest
Output
1
Busy signal for
reconfig_readdata
.
reconfig_writedata
Input
32
When
reconfig_write
is high,
reconfig_writedata
holds valid write data.
Related Information
Defines the Avalon-MM interface specification, including the behavior of the output signals and the
expected behavior of the input signals.
UG-01128
2015.05.04
Arria 10 Transceiver Reconfiguration Interface Signals
5-17
100G Interlaken MegaCore Function Signals
Altera Corporation
