Performance and Fmax Requirements for 100G
Ethernet Traffic
A
2015.05.04
UG-01128
To achieve 100G Ethernet line rates through the application interface of your 100G Interlaken IP core,
you must run the transmit side and receiver side user interface clocks
tx_usr_clk
and
rx_usr_clk
at the
following minimum required operating frequency:
• 300 MHz in single segment mode and in 24 lane variations
(2)
• 225 MHz in 12 lane variations in dual segment mode
The following discussion describes the packet rate calculation that supports this requirement.
Figure A-1: Interlaken Ethernet Packet
To transmit a minimum size (64-byte) Ethernet packet, the Interlaken link transmitter must send 672 bits
of data.
Preamble
8 Bytes
Minimum Packet
64 Bytes
Interpacket Gap
12 Bytes
672 Bits
To support an Ethernet line rate of 100Gb/s, the Interlaken link must process 1000 bits in 10ns. The
following calculation derives the required clock frequency.
.
150 million packets/sec
100 x 1,000,000,000 bits/sec
.
672 = 148.8 million packets/sec
This packet rate requires that the user interface handle one packet per cycle if the operating clock runs at
150 MHz, or one packet per two cycles if the operating clock runs at 300 MHz.
In dual segment mode, because the final cycle of one packet can overlap with the initial cycle of another
packet, the operating clock frequency requirements are derived from the average number of cycles
required for a single packet in back-to-back traffic. The calculations that follow show that the minimum
operating clock frequency in dual segment mode is 225 MHz.
(2)
The restriction to a minimum of 300 MHz in dual segment mode in 24 lane variations is an artifact of the
clocking scheme in this IP core.
©
