Altera 100G Interlaken MegaCore Function User Manual
Page 107
Date
ACDS
Version
Changes Made
2014.12.15
14.1
• Updated release-specific information for the software release v14.1,
including new resource utilization numbers and new Arria 10 speed
grade notation.
• Updated for new Quartus II IP Catalog, which replaces the MegaWizard
Plug-In Manager starting in the Quartus II software v14.0. Changes are
located primarily in Getting Started With the 100G Interlaken IP Core
chapter. Reordered the chapter to accommodate the new descriptions.
• Fixed speed grade information for Arria 10 devices in Device Speed
Grade Support section.
• Removed
mm_clk_locked
signal. Signal is removed in the IP core v14.0
and later.
• Corrected management interface read operation waveform and require‐
ments. In the IP core v13.1 and later, the read data is valid two cycles
after
mm_read
is asserted, not one cycle as was previously shown.
• Corrected instructions to connect the external TX PLL to include the
tx_
cal_busy
signal, and added example figure to illustrate the required
connections between the IP core and an ATX PLL. Changes are located in
Adding the External PLL section.
• In relevant parameter description sections, removed note to ignore the
compilation warnings if you turn off any of the following parameters.
The issue is fixed in the SDC file in the IP core version 14.0 and later.
• Include advanced error reporting and handling
• Enable M20K ECC support
• Include diagnostic features
• Include in-band flow control functionality
• Removed
CNTR_BITS
RTL parameter. Parameter is removed in the IP
core v14.0 and later.
• Added information to IP Core Reset section about the current required
wait from reset to successful register access in IP Core Reset section.
• Corrected width of
reconfig_waitrequest
signal to one bit. This signal
has been a single bit in all versions that support Arria 10 devices, starting
with the IP core version 13.1 Arria 10 Edition.
• Corrected the text that describes the trade-offs between enabling and
disabling the Enable M20K ECC support parameter.
• Added information about turning on and off loopback mode in two new
sections, External Loopback Mode and Internal Serial Loopback Mode, in
IP Core Test Features chapter.
• Clarified that the testbench and example design are generated only if you
specify the IP core synthesis and simulation models are in Verilog HDL.
The IP core does not support VHDL models, despite the fact that in the
IP core v14.0 and later, the parameter editor appears to offer that option.
• Fixed assorted typos and formatting issues.
