Installation and Licensing
The SerialLite II MegaCore function is part of the MegaCore IP Library, which is
distributed with the Quartus II software and downloadable from the Altera
website,
You can use Altera's free OpenCore Plus evaluation feature to evaluate the MegaCore
function in simulation and in hardware before you purchase a license. You need to
purchase a license for the MegaCore function only when you are satisfied with its
functionality and performance, and you want to take your design to production.
After you purchase a license for the SerialLite II MegaCore function, you can request a
license file from the Altera website a
and install it on your
computer. When you request a license file, Altera emails you a license.dat file. If you
do not have internet access, contact your local Altera representative.
