Delta Electronics AC Motor Drive VFD-EL User Manual
Page 68
Chapter 4 Parameters|
Revision August 2008, 2ELE, V1.02
4-25
Output Signal for Base Block
Applications Purpose
Functions
Related
Parameters
General application
Provide a signal for
running status
When executing Base Block, a signal
is given for external system or control
wiring.
03.00
Overheat Warning for Heat Sink
Applications Purpose
Functions
Related
Parameters
General application
For safety
When heat sink is overheated, it will
send a signal for external system or
control wiring.
03.00
Multi-function Analog Output
Applications Purpose
Functions
Related
Parameters
General application
Display running
status
The value of frequency, output
current/voltage can be read by
connecting a frequency meter or
voltage/current meter.
03.06
