B.8 Fieldbus Modules
B.8.1 DeviceNet Communication Module (CME-DN01)
B.8.1.1 Panel Appearance and Dimensions
1. For RS-485 connection to VFD-EL 2. Communication port for connecting DeviceNet
network 3. Address selector 4. Baud rate selector 5. Three LED status indicators for monitor.
(Refer to the figure below)
72.2 [2.84]
57
.3
[2.
26]
14
.3
[0.
57]
59
.7
[2.
35]
3.5 [0.14] 35.8 [1.41]
CME-DN01
ADD1 ADD2
SP
500K
250K 125K
BAUD
MOD NET
UNIT: mm(inch)
1
5 4 3
2
B.8.1.2 Wiring and Settings
Refer to following diagram for details.
CME-DN01
ADD1 ADD2
SP
500K
250K 125K
BAUD
MOD NET
MAC address Date Rate
CAN-L V+
Empty
Pin
CAN-H V-
1: Reserved
2: EV
5: SG+
6: Reserved
7: Reserved
8: Reserved
3: GND
4: SG-
Setting baud rate
BAUD
0
Switch
Value
Baud
Rate
0 125K
1 250K
2 500K
Other AUTO
Setting MAC addresses:
use decimal system.
ADD1 ADD2
