Chapter 4 Parameters|
4-64 Revision August 2008, 2ELE, V1.02
0 1 0 1 1 0
Weights
Bit
0=external terminal
1=internal terminal
MI1
MI2
MI3
MI4
MI5
MI6
This parameter is used to set the internal terminal action via keypad or communication.
For standard AC motor drive, the multi-function input terminals are MI1 to MI6 as shown in the
following.
1 2 3 4 5 0
0=set internal terminal to be OFF
1= ON set internal terminal to be
MI1
MI2
MI3
MI4
MI5
MI6
Weights
Bit
For example, if setting MI3, MI5 and MI6 to be ON, Pr.04.28 should be set to
bit5X2 5 +bit4X2 4 +bit2X2 2 = 1X2 5 +1X2 4 +1X2 2 = 32+16+4=52 as shown in the following.
0 1 0 1 1 0
Weights
Bit
0=OFF
1=ON
MI1
MI2
MI3
MI4
MI5
MI6
04.28 Internal Terminal Status Unit: 1
Settings 0 to 4095 Factory Setting: 0
