Chapter 4 Parameters|
4-8 Revision August 2008, 2ELE, V1.02
Parameter Explanation Settings
Factory
Setting
Customer
11: Preliminary count value attained
12: Over Voltage Stall supervision
13: Over Current Stall supervision
14: Heat sink overheat warning
15: Over Voltage supervision
16: PID supervision
17: Forward command
18: Reverse command
19: Zero speed output signal
20: Warning(FbE,Cexx, AoL2, AUE, SAvE)
21: Brake control (Desired frequency
attained)
22: AC motor drive ready
03.01 Reserved
03.02 Desired Frequency
Attained
0.00 to 600.0Hz 0.00
0: Analog frequency meter
03.03
Analog Output
Signal Selection
(AFM)
1: Analog current meter
0
03.04 Analog Output Gain 1 to 200% 100
03.05 Terminal Count
Value
0 to 9999 0
03.06
Preliminary Count
Value
0 to 9999 0
0: Terminal count value attained, no EF
display
03.07
EF Active When
Terminal Count
Value Attained
1: Terminal count value attained, EF active
0
0: Fan always ON
1: 1 minute after AC motor drive stops, fan
will be OFF
2: Fan ON when AC motor drive runs, fan
OFF when AC motor drive stops
03.08 Fan Control
3: Fan ON when preliminary heatsink
temperature attained
0
03.09 Reserved
