Chapter 4 Parameters|
Revision August 2008, 2ELE, V1.02 4-3
Parameter Explanation Settings
Factory
Setting
Customer
7: Display output power (P)
8: Display PID setting and feedback signal
9: Display AVI (I) (V)
10: Display ACI (i) (mA)
11: Display the temperature of IGBT (h) ( °C)
00.05
User-Defined
Coefficient K
0. 1 to 160.0 1.0
00.06 Software Version Read-only #.##
00.07 Reserved
00.08 Password Input 0 to 9999 0
00.09 Password Set 0 to 9999 0
00.10 Reserved
00.11 Reserved
00.12
50Hz Base Voltage
Selection
0: 230V/400V
1: 220V/380V
0
00.13
User-defined Value 1
(correspond to max.
frequency)
0 to 9999
0
00.14
Position of Decimal
Point of User-
defined Value 1
0 to 3
0
Group 1 Basic Parameters
Parameter Explanation Settings
Factory
Setting
Customer
01.00
Maximum Output
Frequency (Fmax)
50.00 to 600.0 Hz 60.00
01.01
Maximum Voltage
Frequency (Fbase)
0.10 to 600.0 Hz 60.00
115V/230V series: 0.1V to 255.0V 220.0
01.02
Maximum Output
Voltage (Vmax)
460V series: 0.1V to 510.0V 440.0
01.03
Mid-Point Frequency
(Fmid)
0.10 to 600.0 Hz 1.50
