Delta Electronics AC Motor Drive VFD-EL User Manual
Page 47
Chapter 4 Parameters|
4-4
Revision August 2008, 2ELE, V1.02
Parameter Explanation
Settings
Factory
Setting
Customer
115V/230V series: 0.1V to 255.0V
10.0
01.04
Mid-Point Voltage
(Vmid)
460V series: 0.1V to 510.0V
20.0
01.05
Minimum Output
Frequency (Fmin)
0.10 to 600.0 Hz
1.50
115V/230V series: 0.1V to 255.0V
10.0
01.06
Minimum Output
Voltage (Vmin)
460V series: 0.1V to 510.0V
20.0
01.07
Output Frequency
Upper Limit
0.1 to 120.0%
110.0
01.08
Output Frequency
Lower Limit
0.0 to100.0 %
0.0
01.09
Accel Time 1
0.1 to 600.0 / 0.01 to 600.0 sec
10.0
01.10
Decel Time 1
0.1 to 600.0 / 0.01 to 600.0 sec
10.0
01.11
Accel Time 2
0.1 to 600.0 / 0.01 to 600.0 sec
10.0
01.12
Decel Time 2
0.1 to 600.0 / 0.01 to 600.0 sec
10.0
01.13 Jog
Acceleration
Time
0.1 to 600.0 / 0.01 to 600.0 sec
1.0
01.14 Jog
Deceleration
Time
0.1 to 600.0 / 0.01 to 600.0 sec
1.0
01.15
Jog Frequency
0.10 Hz to Fmax (Pr.01.00) Hz
6.00
0: Linear Accel/Decel
1: Auto Accel, Linear Decel
2: Linear Accel, Auto Decel
3: Auto Accel/Decel (Set by load)
01.16
Auto acceleration /
deceleration (refer
to Accel/Decel time
setting)
4: Auto Accel/Decel (set by Accel/Decel
Time setting)
0
01.17
Acceleration S-
Curve
0.0 to 10.0 / 0.00 to 10.00 sec
0.0
01.18
Deceleration S-
Curve
0.0 to 10.0 / 0.00 to 10.00 sec
0.0
0: Unit: 0.1 sec
01.19
Accel/Decel Time
Unit
1: Unit: 0.01 sec
0
