Chapter 4 Parameters|
4-12 Revision August 2008, 2ELE, V1.02
Parameter Explanation Settings
Factory
Setting
Customer
05.05 6th Step Speed
Frequency
0.00 to 600.0 Hz 0.00
05.06 7th Step Speed
Frequency
0.00 to 600.0 Hz 0.00
05.07 8th Step Speed
Frequency
0.00 to 600.0 Hz 0.00
05.08 9th Step Speed
Frequency
0.00 to 600.0 Hz 0.00
05.09 10th Step Speed
Frequency 0.00 to 600.0 Hz 0.00
05.10 11th Step Speed
Frequency 0.00 to 600.0 Hz 0.00
05.11 12th Step Speed
Frequency 0.00 to 600.0 Hz 0.00
05.12 13th Step Speed
Frequency 0.00 to 600.0 Hz 0.00
05.13 14th Step Speed
Frequency 0.00 to 600.0 Hz 0.00
05.14 15th Step Speed
Frequency 0.00 to 600.0 Hz 0.00
Group 6 Protection Parameters
Parameter Explanation Settings
Factory
Setting
Customer
115/230V series: 330.0V to 410.0V 390.0V
460V series: 660.0V to 820.0V 780.0V 06.00
Over-Voltage Stall
Prevention
0.0: Disable over-voltage stall prevention
06.01
Over-Current Stall
Prevention during
Accel
0:Disable
20 to 250%
170
06.02
Over-Current Stall
Prevention during
Operation
0:Disable
20 to 250%
170
0: Disabled 06.03 Over-Torque
Detection Mode
(OL2)
1: Enabled during constant speed operation.
After the over-torque is detected, keep
running until OL1 or OL occurs.
0
